| Weight |
600 kg |
| Dimensions |
100 × 60 × 70 cm |
Technical parameters
| TECHNICAL DATA OF YX3 SERIES |
| NO. |
Type |
Output |
Speed |
Amps |
EFF. |
P.F. |
LRT |
LRA |
BDT |
Noise |
Voltage |
| kW |
r/min |
A |
% |
Cosφ |
RLT |
RLA |
RLT |
LwdB(A) |
V |
| 1 |
YX3-80M1-2 |
0.75 |
2860 |
1.77 |
77.5 |
0.83 |
2.3 |
6.8 |
2.3 |
62 |
415 |
| 2 |
YX3-80M2-2 |
1.1 |
2880 |
2.43 |
82.8 |
0.83 |
2.3 |
7.3 |
2.3 |
62 |
415 |
| 3 |
YX3-90S-2 |
1.5 |
2890 |
3.23 |
84.1 |
0.84 |
2.3 |
7.6 |
2.3 |
67 |
415 |
| 4 |
YX3-90L-2 |
2.2 |
2890 |
4.59 |
85.6 |
0.85 |
2.3 |
7.8 |
2.3 |
67 |
415 |
| 5 |
YX3-100L-2 |
3 |
2890 |
6.04 |
86.7 |
0.87 |
2.3 |
8.1 |
2.3 |
74 |
415 |
| 6 |
YX3-112M-2 |
4 |
2910 |
7.88 |
87.6 |
0.88 |
2.3 |
8.3 |
2.3 |
77 |
415 |
| 7 |
YX3-132S1-2 |
5.5 |
2910 |
10.7 |
88.6 |
0.88 |
2.2 |
8 |
2.3 |
79 |
415 |
| 8 |
YX3-132S2-2 |
7.5 |
2910 |
14.3 |
89.5 |
0.89 |
2.2 |
7.8 |
2.3 |
79 |
415 |
| 9 |
YX3-160M1-2 |
11 |
2940 |
20.8 |
90.5 |
0.89 |
2.2 |
7.9 |
2.3 |
81 |
415 |
| 10 |
YX3-160M2-2 |
15 |
2940 |
28 |
91.3 |
0.89 |
2.2 |
8 |
2.3 |
81 |
415 |
| 11 |
YX3-160L-2 |
18.5 |
2940 |
34.4 |
91.8 |
0.89 |
2.2 |
8.1 |
2.3 |
81 |
415 |
| 12 |
YX3-180M-2 |
22 |
2950 |
40.7 |
92.2 |
0.89 |
2.2 |
8.2 |
2.3 |
83 |
415 |
| 13 |
YX3-200L1-2 |
30 |
2960 |
55.1 |
92.9 |
0.89 |
2.2 |
7.5 |
2.3 |
84 |
415 |
| 14 |
YX3-200L2-2 |
37 |
2960 |
67.7 |
93.3 |
0.89 |
2.2 |
7.5 |
2.3 |
84 |
415 |
| 15 |
YX3-225M-2 |
45 |
2960 |
82 |
93.7 |
0.89 |
2.2 |
7.6 |
2.3 |
86 |
415 |
| 16 |
YX3-250M-2 |
55 |
2970 |
100 |
94 |
0.89 |
2.2 |
7.6 |
2.3 |
89 |
415 |
| 17 |
YX3-280S-2 |
75 |
2970 |
135 |
94.6 |
0.89 |
2 |
6.9 |
2.3 |
91 |
415 |
| 18 |
YX3-280M-2 |
90 |
2970 |
162 |
95 |
0.89 |
2 |
7 |
2.3 |
91 |
415 |
| 19 |
YX3-315S-2 |
110 |
2970 |
195 |
95 |
0.9 |
2 |
7.1 |
2.2 |
92 |
415 |
| 20 |
YX3-315M-2 |
132 |
2970 |
234 |
95.4 |
0.9 |
2 |
7.1 |
2.2 |
92 |
415 |
| 21 |
YX3-315L1-2 |
160 |
2970 |
280.1 |
95.4 |
0.91 |
2 |
7.1 |
2.2 |
92 |
415 |
| 22 |
YX3-315L2-2 |
200 |
2970 |
350 |
95.4 |
0.91 |
2 |
7.1 |
2.2 |
92 |
415 |
| 23 |
YX3-355M-2 |
250 |
2980 |
436 |
95.8 |
0.91 |
2 |
7.1 |
2.2 |
100 |
415 |
| 24 |
YX3-355L-2 |
315 |
2980 |
549 |
95.8 |
0.91 |
2 |
7.1 |
2.2 |
100 |
415 |
| 25 |
YX3-80M1-4 |
0.55 |
1430 |
1.38 |
80.7 |
0.75 |
2.3 |
6.3 |
2.3 |
56 |
415 |
| 26 |
YX3-80M2-4 |
0.75 |
1430 |
1.85 |
82.3 |
0.75 |
2.3 |
6.5 |
2.3 |
56 |
415 |
| 27 |
YX3-90S-4 |
1.1 |
1430 |
2.66 |
83.8 |
0.75 |
2.3 |
6.6 |
2.3 |
59 |
415 |
| 28 |
YX3-90L-4 |
1.5 |
1430 |
3.58 |
85 |
0.75 |
2.3 |
6.9 |
2.3 |
59 |
415 |
| 29 |
YX3-100L1-4 |
2.2 |
1450 |
4.78 |
86.4 |
0.81 |
2.3 |
7.5 |
2.3 |
64 |
415 |
| 30 |
YX3-100L2-4 |
3 |
1450 |
6.36 |
87.4 |
0.82 |
2.3 |
7.6 |
2.3 |
64 |
415 |
| 31 |
YX3-112M-4 |
4 |
1450 |
8.39 |
88.3 |
0.82 |
2.3 |
7.7 |
2.3 |
65 |
415 |
| 32 |
YX3-132S-4 |
5.5 |
1450 |
11.4 |
89.2 |
0.82 |
2 |
7.5 |
2.3 |
71 |
415 |
| 33 |
YX3-132M-4 |
7.5 |
1450 |
15.2 |
90.1 |
0.83 |
2 |
7.4 |
2.3 |
71 |
415 |
| 34 |
YX3-160M-4 |
11 |
1470 |
21.6 |
91 |
0.85 |
2.2 |
7.5 |
2.3 |
73 |
415 |
| 35 |
YX3-160L-4 |
15 |
1470 |
28.9 |
91.8 |
0.86 |
2.2 |
7.5 |
2.3 |
73 |
415 |
| 36 |
YX3-180M-4 |
18.5 |
1470 |
35.4 |
92.2 |
0.86 |
2.2 |
7.7 |
2.3 |
76 |
415 |
| 37 |
YX3-180L-4 |
22 |
1470 |
42 |
92.6 |
0.86 |
2.2 |
7.8 |
2.3 |
76 |
415 |
| 38 |
YX3-200L-4 |
30 |
1470 |
56.9 |
93.2 |
0.86 |
2.2 |
7.2 |
2.3 |
76 |
415 |
| 39 |
YX3-225S-4 |
37 |
1480 |
69.8 |
93.6 |
0.86 |
2.2 |
7.3 |
2.3 |
78 |
415 |
| 40 |
YX3-225M-4 |
45 |
1480 |
84.7 |
93.9 |
0.86 |
2.2 |
7.4 |
2.3 |
78 |
415 |
| 41 |
YX3-250M-4 |
55 |
1480 |
103 |
94.2 |
0.86 |
2.2 |
7.4 |
2.3 |
79 |
415 |
| 42 |
YX3-280S-4 |
75 |
1480 |
137 |
94.7 |
0.88 |
2.2 |
6.7 |
2.3 |
80 |
415 |
| 43 |
YX3-280M-4 |
90 |
1480 |
164 |
95 |
0.88 |
2.2 |
6.9 |
2.3 |
80 |
415 |
| 44 |
YX3-315S-4 |
110 |
1480 |
199 |
95.4 |
0.88 |
2.2 |
6.9 |
2.2 |
88 |
415 |
| 45 |
YX3-315M-4 |
132 |
1480 |
239 |
95.4 |
0.88 |
2.2 |
6.9 |
2.2 |
88 |
415 |
| 46 |
YX3-315L1-4 |
160 |
1480 |
286 |
95.4 |
0.89 |
2.2 |
6.9 |
2.2 |
88 |
415 |
| 47 |
YX3-315L2-4 |
200 |
1480 |
358 |
95.4 |
0.89 |
2.2 |
6.9 |
2.2 |
88 |
415 |
| 48 |
YX3-355M-4 |
250 |
1490 |
441 |
95.8 |
0.9 |
2.2 |
6.9 |
2.2 |
95 |
415 |
| 49 |
YX3-355L-4 |
315 |
1490 |
555 |
95.8 |
0.9 |
2.2 |
6.9 |
2.2 |
95 |
415 |
| 50 |
YX3-90S-6 |
0.75 |
940 |
2.04 |
77.7 |
0.72 |
2.1 |
5.8 |
2.1 |
57 |
415 |
| 51 |
YX3-90L-6 |
1.1 |
940 |
2.87 |
79.9 |
0.73 |
2.1 |
5.9 |
2.1 |
57 |
415 |
| 52 |
YX3-100L-6 |
1.5 |
940 |
3.78 |
81.5 |
0.74 |
2.1 |
6 |
2.1 |
61 |
415 |
| 53 |
YX3-112M-6 |
2.2 |
950 |
5.42 |
83.4 |
0.74 |
2.1 |
6 |
2.1 |
65 |
415 |
| 54 |
YX3-132S-6 |
3 |
960 |
7.26 |
84.9 |
0.74 |
2 |
6.2 |
2.1 |
69 |
415 |
| 55 |
YX3-132M1-6 |
4 |
970 |
9.54 |
86.1 |
0.74 |
2 |
6.8 |
2.1 |
69 |
415 |
| 56 |
YX3-132M2-6 |
5.5 |
970 |
12.7 |
87.4 |
0.75 |
2 |
7.1 |
2.1 |
69 |
415 |
| 57 |
YX3-160M-6 |
7.5 |
970 |
16.4 |
89 |
0.78 |
2.1 |
6.7 |
2.1 |
73 |
415 |
| 58 |
YX3-160L-6 |
11 |
970 |
23.5 |
90 |
0.79 |
2.1 |
6.9 |
2.1 |
73 |
415 |
| 59 |
YX3-180L-6 |
15 |
980 |
30.9 |
91 |
0.81 |
2 |
7.2 |
2.1 |
73 |
415 |
| 60 |
YX3-200L1-6 |
18.5 |
980 |
37.9 |
91.5 |
0.81 |
2.1 |
7.2 |
2.1 |
73 |
415 |
| 61 |
YX3-200L2-6 |
22 |
980 |
44.3 |
92 |
0.82 |
2.1 |
7.3 |
2.1 |
73 |
415 |
| 62 |
YX3-225M-6 |
30 |
980 |
60.1 |
92.5 |
0.82 |
2 |
7.1 |
2.1 |
74 |
415 |
| 63 |
YX3-250M-6 |
37 |
980 |
72 |
93 |
0.84 |
2.1 |
7.1 |
2.1 |
76 |
680 |
| 64 |
YX3-280S-6 |
45 |
980 |
85 |
93.5 |
0.86 |
2.1 |
7.2 |
2 |
78 |
680 |
| 65 |
YX3-280M-6 |
55 |
980 |
104 |
93.8 |
0.86 |
2.1 |
7.2 |
2 |
78 |
415 |
| 66 |
YX3-315S-6 |
75 |
990 |
142 |
94.2 |
0.85 |
2 |
6.7 |
2 |
83 |
415 |
| 67 |
YX3-315M-6 |
90 |
990 |
172 |
94.5 |
0.84 |
2 |
6.7 |
2 |
83 |
415 |
| 68 |
YX3-315L1-6 |
110 |
990 |
207 |
95 |
0.85 |
2 |
6.7 |
2 |
83 |
415 |
| 69 |
YX3-315L2-6 |
132 |
990 |
245 |
95 |
0.86 |
2 |
6.7 |
2 |
83 |
415 |
| 70 |
YX3-355M1-6 |
160 |
990 |
294 |
95 |
0.87 |
2 |
6.7 |
2 |
85 |
415 |
| 71 |
YX3-355M2-6 |
200 |
990 |
368 |
95 |
0.87 |
2 |
6.7 |
2 |
85 |
415 |
| 72 |
YX3-355L-6 |
250 |
990 |
460 |
95 |
0.87 |
2 |
6.7 |
2 |
85 |
415 |
Installation dimension

| Frame without feet and end-shield with flange(IM B35) |
| a |
FRAME
SIZE |
POLES |
A |
A/2 |
B |
C |
D |
E |
F |
G |
H |
K |
M |
N |
P |
S |
T |
FLANGE |
AB |
AC |
AD |
HD |
L |
DH* |
| HOLES |
| 80M |
2 4 6 |
125 |
62.5 |
100 |
50 |
19 |
40 |
6 |
15.5 |
80 |
10 |
165 |
130 |
200 |
12 |
3.5 |
4 |
165 |
158 |
140 |
220 |
300 |
M6x16 |
| 90S |
2 4 6 |
140 |
70 |
100 |
56 |
24 |
50 |
8 |
20 |
90 |
10 |
165 |
130 |
200 |
12 |
3.5 |
4 |
180 |
177 |
160 |
245 |
330 |
M8x19 |
| 90L |
2 4 6 |
140 |
70 |
125 |
56 |
24 |
50 |
8 |
20 |
90 |
10 |
165 |
130 |
200 |
12 |
3.5 |
4 |
180 |
177 |
160 |
245 |
360 |
M8x19 |
| 100L |
2 4 6 |
160 |
80 |
140 |
63 |
28 |
60 |
8 |
24 |
100 |
12 |
215 |
180 |
250 |
15 |
4 |
4 |
205 |
198 |
172 |
270 |
400 |
M10x22 |
| 112M |
2 4 6 |
190 |
95 |
140 |
70 |
28 |
60 |
8 |
24 |
112 |
12 |
215 |
180 |
250 |
15 |
4 |
4 |
230 |
220 |
190 |
300 |
435 |
M10x22 |
| 132S |
2 4 6 |
216 |
108 |
140 |
89 |
38 |
80 |
10 |
33 |
132 |
12 |
265 |
230 |
300 |
15 |
4 |
4 |
270 |
259 |
210 |
345 |
470 |
M12x28 |
| 132M |
2 4 6 |
216 |
108 |
178 |
89 |
38 |
80 |
10 |
33 |
132 |
12 |
265 |
230 |
300 |
15 |
4 |
4 |
270 |
259 |
210 |
345 |
510 |
M12x28 |
| 160M |
2 4 6 |
254 |
127 |
210 |
108 |
42 |
110 |
12 |
37 |
160 |
15 |
300 |
250 |
350 |
19 |
5 |
4 |
320 |
315 |
255 |
420 |
615 |
M16x36 |
| 160L |
2 4 6 |
254 |
127 |
254 |
108 |
42 |
110 |
12 |
37 |
160 |
15 |
300 |
250 |
350 |
19 |
5 |
4 |
320 |
315 |
255 |
420 |
660 |
M16x36 |
| 180M |
2 4 6 |
279 |
139.5 |
241 |
121 |
48 |
110 |
14 |
42.5 |
180 |
15 |
300 |
250 |
350 |
19 |
5 |
4 |
355 |
355 |
280 |
455 |
700 |
M16x36 |
| 180L |
2 4 6 |
279 |
139.5 |
279 |
121 |
48 |
110 |
14 |
42.5 |
180 |
15 |
300 |
250 |
350 |
19 |
5 |
4 |
355 |
355 |
280 |
455 |
740 |
M16x36 |
| 200L |
2 4 6 |
318 |
159 |
305 |
133 |
55 |
110 |
16 |
49 |
200 |
19 |
350 |
300 |
400 |
19 |
5 |
4 |
395 |
397 |
305 |
505 |
770 |
M20x42 |
| 225S |
4 |
356 |
178 |
286 |
149 |
60 |
140 |
18 |
53 |
225 |
19 |
400 |
350 |
450 |
19 |
5 |
8 |
435 |
445 |
335 |
560 |
815 |
M20x42 |
| 225M |
2 |
356 |
178 |
311 |
149 |
55 |
110 |
16 |
49 |
225 |
19 |
400 |
350 |
450 |
19 |
5 |
8 |
435 |
445 |
335 |
560 |
820 |
M20x42 |
| 4 6 |
356 |
178 |
311 |
149 |
60 |
140 |
18 |
53 |
225 |
19 |
400 |
350 |
450 |
19 |
5 |
8 |
435 |
445 |
335 |
560 |
845 |
M20x42 |
| 250M |
2 |
406 |
203 |
349 |
168 |
60 |
140 |
18 |
53 |
250 |
24 |
500 |
450 |
550 |
19 |
5 |
8 |
490 |
485 |
370 |
615 |
920 |
M20x42 |
| 4 6 |
406 |
203 |
349 |
168 |
65 |
140 |
18 |
58 |
250 |
24 |
500 |
450 |
550 |
19 |
5 |
8 |
490 |
485 |
370 |
615 |
920 |
M20x42 |
| 280S |
2 |
457 |
228.5 |
368 |
190 |
65 |
140 |
18 |
58 |
280 |
24 |
500 |
450 |
550 |
19 |
5 |
8 |
550 |
547 |
410 |
680 |
995 |
M20x42 |
| 4 6 |
457 |
228.5 |
368 |
190 |
75 |
140 |
20 |
67.5 |
280 |
24 |
500 |
450 |
550 |
19 |
5 |
8 |
550 |
547 |
410 |
680 |
995 |
M20x42 |
| 280M |
2 |
457 |
228.5 |
419 |
190 |
65 |
140 |
18 |
58 |
280 |
24 |
500 |
450 |
550 |
19 |
5 |
8 |
550 |
547 |
410 |
680 |
1045 |
M20x42 |
| 4 6 |
457 |
228.5 |
419 |
190 |
75 |
140 |
20 |
67.5 |
280 |
24 |
500 |
450 |
550 |
19 |
5 |
8 |
550 |
547 |
410 |
680 |
1045 |
M20x42 |
| 315S |
2 |
508 |
254 |
406 |
216 |
65 |
140 |
18 |
68 |
315 |
28 |
600 |
550 |
660 |
24 |
6 |
8 |
635 |
620 |
530 |
845 |
1185 |
M20x42 |
| 4 6 |
508 |
254 |
406 |
216 |
80 |
170 |
22 |
71 |
315 |
28 |
600 |
550 |
660 |
24 |
6 |
8 |
635 |
620 |
530 |
845 |
1220 |
M20x42 |
| 315M |
2 |
508 |
254 |
457 |
216 |
65 |
140 |
18 |
58 |
315 |
28 |
600 |
550 |
660 |
24 |
6 |
8 |
635 |
620 |
330 |
845 |
1290 |
M20x42 |
| 4 6 |
508 |
254 |
457 |
216 |
80 |
170 |
22 |
71 |
315 |
28 |
600 |
550 |
660 |
24 |
6 |
8 |
635 |
620 |
530 |
845 |
1325 |
M20x42 |
| 315L |
2 |
508 |
254 |
508 |
216 |
65 |
140 |
18 |
58 |
315 |
28 |
600 |
550 |
660 |
24 |
6 |
8 |
635 |
620 |
530 |
845 |
1290 |
M20x42 |
| 4 6 |
508 |
254 |
508 |
216 |
80 |
170 |
22 |
71 |
315 |
28 |
600 |
550 |
660 |
24 |
6 |
8 |
635 |
620 |
530 |
845 |
1325 |
M20x42 |
| 355M |
2 |
610 |
305 |
560 |
254 |
75 |
140 |
20 |
67.5 |
355 |
28 |
740 |
680 |
800 |
24 |
6 |
8 |
730 |
698 |
655 |
1010 |
1500 |
M20x42 |
| 4 6 |
610 |
305 |
560 |
254 |
95 |
170 |
25 |
86 |
355 |
28 |
740 |
680 |
800 |
24 |
6 |
8 |
730 |
698 |
655 |
1010 |
1530 |
M20x42 |
| 355L |
2 |
610 |
305 |
630 |
254 |
75 |
140 |
20 |
67.5 |
355 |
28 |
740 |
680 |
800 |
24 |
6 |
8 |
730 |
698 |
655 |
1010 |
1500 |
M20x42 |
| 4 6 |
610 |
305 |
630 |
254 |
95 |
170 |
25 |
86 |
355 |
28 |
740 |
680 |
800 |
24 |
6 |
8 |
730 |
698 |
655 |
1010 |
1530 |
M20x42 |
Bearing specifications
| Frame size |
Poles |
Drive End |
Non-Drive End |
| International type |
International type |
| 80 |
2-4 |
6204-2RZ |
6204-2RZ |
| 90 |
2-6 |
6205-2RZ |
6205-2RZ |
| 100 |
2-6 |
6206-2RZ |
6206-2RZ |
| 112 |
2-6 |
6306-2RZ |
6306-2RZ |
| 132 |
2-6 |
6308-2RZ |
6308-2RZ |
| 160 |
2-6 |
6309-2RZC3 |
6309-2RZC3 |
| 180 |
2-6 |
6311C3 |
6311C3 |
| 200 |
2-6 |
6312C3 |
6312C3 |
| 225 |
2-6 |
6313C3 |
6313C3 |
| 250 |
2-6 |
6314C3 |
6314C3 |
| 280 |
2 |
6314C3 |
6314C3 |
| 4-6 |
6317C3 |
6317C3 |
| 315 |
2 |
6317C3 |
6317C3 |
| 4-6 |
NU319C3 |
6319C3 |
| 355 |
2 |
6319C3 |
6319C3 |
| 4-6 |
NU322C3 |
NU322C3 |
The main dimensions of the box
| Classified number |
Frame size |
Max.F.Amps |
Entery hole size |
| International standard |
| 1 |
H80 |
2.6 |
2×M20×15 |
| 2 |
H90-100 |
6.8 |
2×M25×1.5 |
| 3 |
H112-132 |
15.4 |
2×M35×1.5 |
| 4 |
H160-180 |
42.5 |
2×M40×1.5 |
| 5 |
H200-225 |
84.2 |
2×M50×1.5 |
| 6 |
H250-280 |
166.6 |
2×M63×1.5 |
| 7 |
H315 |
358 |
2×M63×1.5 |
| 8 |
H355 |
546 |
2×M63×1.5 |
